Product Type

MTXXXX002

General

Appearance

2.5

Interface

SAS

Performance

Capacity

60GB | 120GB | 240GB | 480GB

Sustained Read

500MB / S | 500MB / S | 500MB / S | 500MB / S

Sequential Write

410MB / S | 470MB / S | 480MB / S | 500MB / S

Random IOPS

4KB Random Read IOPS

80K

4KB random write IOPS

30K

Average access time

For 0.2ms

Storage media

NAND Flash

MLC

Power consumption

Input voltage

5V±5％

Idle

0.5W

Active

2.0W

Reliability and stability

Writing life

@ 100GBytes 10 years to write, erase 60GB day

Reading life

Unlimited

Wear leveling algorithm

Dynamic and static balance erase

Data Retention

10 years 25 & ordm; C

MTBF

1300000 Hour

ECC

BCH ECC 55bits support 512 bytes

Bad Block Management

Automatic bad block management system

Environment

Working temperature

0〜70℃

Nonoperating

-40〜85℃

Shock

Vibration

Humidity

Insurance

2 years

Available Units

Available

Test Platform

CPU: Intel & reg; Xeon & reg; E5606 & times; 2 Motherboard: SUPERMICRO & times; 8 DTL-6 Power: Huntkey 510W (2U only) Memory: Kingston DDR3 1333 2G (KVR1333D3N9 / 2G) & times; 4 Operating System: Microsoft Windows Services 2003 SP1

Test Software

Physical Dimensions and Weight

Height（mm）

Width（mm）

Length（mm）

Weight（g）
